AD Accessory M730

About Product:

AD Accessory M730 is optimized for accessory and cosmetics applications with superior close-coupling features. It is Ideal for small item-level tagging.

Technical Specifications:

Physical Specifications
Antenna Dimensions 30 x 15 mm (1.20 x 0.60 in)
Die-Cut Dimension 33 x 18 mm (1.30 x 0.70 in)
Inlay Substrate PET
Standard Pitch 20 mm (0.787 in)
Web Width 36 mm (1.4 in)
Core Size 76 mm (3 in)
RF Specifications
Frequency Band UHF 860 - 960 MHz
Chip Impinj M730
International Standard ISO 18000-63, EPC Class 1 Gen 2
EPC Memory 128-bit
User Memory 0-bit
TID Memory 96-bit with 48-bit unique serial number
Environment
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Certification ARC spec Q
Quality Management ISO 9001:2015 compliant
Environmental Management ISO 14001:2015 compliant

Industry Segments & Applications:

Apparel
Fashion accessories and clothing item tracking
Healthcare
Pharmaceutical and medical device tracking
  • 🔷 Children Accessories
  • 🔷 Fashion Jewelry and Sunglasses
  • 🔷 Pharmaceutical and Healthcare products
  • 🔷 Small cosmetics items
  • 🔷 Retail inventory management
  • 🔷 Supply chain visibility for small items

Product Code:

  1. Dry Inlay - 3008300 / IL-604218
  2. Wet Inlay - 3008304 / IL-600040
  3. Paper Label - 3008305 / IL-604223

Benefits of Our Product:

​Small Item Optimization

Size 30 x 15 mm antenna design specifically optimized for small item tagging with superior bulk reading performance when attached to accessories and cosmetics.

Compact Form Factor​

33 mm (1.3 inch) compact form factor easily convertible into end-application usage, perfect for space-constrained retail environments.

Superior Close-Coupling​

Excellent performance and superior close-coupling features with M730 chip from Impinj, ideal for dense item environments and bulk reading.

Ready to Solve Your RFID Challenges?

Contact our RFID specialists today to discuss how AD Accessory M730 can address your specific identification and tracking needs.

We'll work with you to design a solution that improves efficiency, reduces costs, and delivers reliable performance.


Get Started Today!

📞 Contact our technical consultation team

📧 Request samples for testing

📋 Custom your quotation based on your requirements​

Contact Us!

All specifications are subject to standard industry tolerances. Performance may vary based on application environment and conditions. Please consult with our technical team for application-specific guidance.*
